Pancake Pressure Vessel | Dual Access Ports | Anti-Corrosion Finish | by Aspen Pumps
The Pancake Pressure Vessel is designed for refrigeration systems, featuring dual access ports for easy monitoring and a solid core block for superior moisture absorption. Ideal for commercial and industrial HVAC applications, it enhances system efficiency by filtering harmful particles and moisture, ensuring optimal performance and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pancake Pressure Vessel | Dual Access Ports | Anti-Corrosion Finish | by Aspen Pumps
Brand: Aspen Pumps
SKU: 303P-409S
Alternatively Known As: SKY Pressure Vessel Pancake, Refrigeration Pressure Vessel, Aspen Pancake Filter Drier
Technical Specifications
- Capacity kW R-22/410A: 28
- Capacity kW R-404A: 24
- Capacity kW R-134A: 21
- Safe Working Pressure (SWP): 3,200 kPa
- Manufactured to ISO/AS 5149.2 standards
- Material composition: 60% MS, 35% AL, 5% AC solid core block
- Connection type: 1-1/8 ID dual access ports
- Dimensions (H x L x W): 118mm x 118mm x 88mm
- Weight: 2.5 kg
Key Features
- Connection: 1-1/8 ID - Dual Access
- Lay-in length: 118 mm
- Diameter: 88 mm
- Solid core block of 60% MS, 35% AL, 5% AC for superior acid, wax, and moisture absorption
- Membrane filter element removes and retains all harmful particles
- Anti-corrosion powder coat finish with chrome flare or solid copper connections
- Dual access ports to monitor pressure differential and contaminant take-up
- Manufactured in accordance with ISO/AS 5149.2 with a Safe Working Pressure (SWP) of 3,200 kPa
Professional Installation Requirements
- Installation should be performed by a qualified refrigeration technician to ensure compliance with safety standards and optimal system performance.
Applications
- Refrigeration systems requiring pressure vessels for refrigerants R-22, R-410A, R-404A, and R-134A
- Commercial and industrial HVAC and refrigeration applications
- Systems requiring contaminant filtration and moisture absorption
Standards & Compliance
- Complies with AS/NZS 5149.2 – Refrigeration systems and heat pumps – Safety and environmental requirements
Environmental Benefits
- Enhances system efficiency by removing harmful particles and moisture, reducing refrigerant leaks and environmental impact
- Durable anti-corrosion finish extends product life, reducing waste and replacement frequency
Warranty Information
Warranty details available upon request from Aspen Pumps; typically includes coverage against manufacturing defects.
Available Now
The Aspen Pumps SKY Pressure Vessel Pancake 303P-409S is available for immediate purchase, ideal for commercial and industrial refrigeration applications.
