PEAK LIMITING Diode 24VDC | Bi-Directional Design | Voltage Spike Protection | Improves Contactor Lifespan | @1 | by Clipsal
The PEAK LIMITING Diode 24VDC is engineered for contactor coil suppression, featuring a bi-directional design that effectively reduces voltage spikes and electrical noise. Ideal for industrial control panels and automation systems, this diode enhances reliability and prolongs the lifespan of contactors, ensuring efficient operation in electrical distribution boards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PEAK LIMITING Diode 24VDC | Bi-Directional Design | Voltage Spike Protection | Improves Contactor Lifespan | @1 | by Clipsal
Brand: Clipsal
SKU: SCHLAD4TBDL
Alternatively Known As: 24VDC Peak Limiting Diode, Contactor Suppression Diode, Clipsal SCHLAD4TBDL, Bi-directional Limiting Diode, Contactor Coil Protection Diode
Technical Specifications
- Operating Voltage: 24VDC
- Type: Bi-directional limiting diode
- Application: Contactor coil suppression
- Mounting: Inline or panel mount
- Current Rating: Suitable for standard contactor coil currents
- Dimensions (H x L x W): 5mm x 30mm x 10mm
- Weight: 0.1 kg
Key Features
- Peak limiting diode for 24VDC applications
- Bi-directional limiting for enhanced protection
- Designed for use with contactors
- Reduces voltage spikes and electrical noise
- Improves contactor lifespan and reliability
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure correct integration with contactor circuits and compliance with safety standards.
Applications
- Industrial control panels
- Automation systems
- Contactor coil protection
- Switchboards
- Electrical distribution boards
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reduces electrical waste by prolonging contactor life
- Minimizes energy loss from voltage spikes
- Improves system efficiency and reliability
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal PEAK LIMITING Diode 24VDC SCHLAD4TBDL is available for immediate purchase. Ideal for industrial automation, control panels, and electrical distribution systems requiring reliable contactor protection.
