Pendant Mount DS-1292ZJ to Suit Box Camera Hikvision
Hikvision pendant mount for box cameras features a drop-down bracket design. Ideal for CCTV installs needing a suspended box camera position.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Hikvision box camera wall bracket, indoor/outdoor camera mounting bracket, DS-1292ZJ camera support
Technical Specifications
- Mount Type: Wall mount bracket
- Material: Aluminium alloy
- Colour: Hikvision white
- Camera Compatibility: Box, bullet and zoom cameras
- Pan Adjustment: 360°
- Tilt Adjustment: -45° to +45°
- Maximum Load: 2 kg
- Cable Management: Built-in cable outlet
- Recommended Mounting Surface: Flat wall
- Compatible Accessory: DS-1275ZJ vertical pole mount
- Dimensions (H x L x W): 97.1mm x 217.9mm x 70mm
- Weight: 0.201 kg
Key Features
- Aluminium alloy construction with surface spray treatment
- Rotatable camera mounting plate
- Built-in cable outlet for concealed cable routing
- Adjustable pan and tilt positioning
- Suitable for indoor and outdoor CCTV installations
- Designed for box, bullet and zoom cameras
- Mounting surface should support at least three times the combined camera and bracket weight
Applications
- Wall mounting Hikvision box cameras
- Indoor CCTV installations
- Outdoor CCTV installations with suitable weather sealing
- Mounting compatible bullet and zoom cameras
- Commercial, industrial and residential surveillance systems
Environmental Benefits
- Aluminium alloy construction is durable and recyclable at end of service life
- Long service life can reduce replacement frequency and installation waste
- Passive mounting accessory requires no electrical power during operation
Warranty Information
Warranty coverage should be confirmed with the authorised Australian Hikvision distributor. Hikvision's published five-year programme is limited to specified premium product lines and does not specifically list this mounting accessory.
Available Now
Available through Hikvision and authorised Australian security equipment distributors.
