Home/Electrical/Accessories/Glands/PES 1100V 60A 4P Gland Bracket | IP55 Rated | Stainless Steel | Flameproof by Ausproof

Trade Discount 19%

PES 1100V 60A 4P Gland Bracket (90) 2.5-C 17-20-G (2S)

PES 1100V 60A 4P Gland Bracket | IP55 Rated | Stainless Steel | Flameproof by Ausproof

BRAND: Ausproof

SKU: RS2316

$2,190.40 List price: $2,720.40

+ −

30 Days Return Delivery Options

PES 1100V 60A 4P Gland Bracket with IP55 rating and durable stainless steel construction—ideal for mining and hazardous environments. Built for safety and reliability, featuring easy termination and flameproof design.

Description

Product Name/Title: PES 1100V 60A 4P Gland Bracket (90) 2.5-C 17-20-G (2S)

Brand: Ausproof

SKU: RS2316

Alternatively Known As: PES 60A Gland Bracket, Ex-certified 4 Pole Connector, Flameproof Gland Bracket, Industrial Electrical Connector 1100V

Technical Specifications

Voltage Range: 660-1,100V
Current Rating: 60A Ex, 90A Non-Ex
Material: Grade 304 Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 3.2kA for 0.2 seconds (2 tests)
Through Fault Current (Earth): 1.0kA for 0.2 seconds (2 tests)
AC High Voltage Withstand (Phase): 4.2kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 60A and 90A
Compliances: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 200mm x 100mm x 150mm
Weight: 5 kg

Key Features

Single solid earth body for enhanced safety
Single piece contacts to prevent hot joints
Easy termination and flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone protection cover
Stainless steel hanging plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.

Applications

Mining and tunnelling operations
Commercial industrial environments
Group 1 hazardous environments requiring flameproof electrical connectors

Standards & Compliance

AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof design enhances safety, reducing risk of environmental hazards
Easy on-site repair reduces waste and downtime

Warranty Information

Standard manufacturer warranty applies; please contact Ausproof for specific warranty details.

Available Now

The Ausproof PES 1100V 60A 4P Gland Bracket is available for immediate purchase, ideal for mining, tunnelling, and hazardous industrial applications.
