PES FR 660V 90A 4P Plug | IP55 Rated | Flameproof Design | Mining Grade by Ausproof

BRAND: Ausproof

SKU: RS2271FR

$856.60 List price: $1,063.90

+ −

30 Days Return Delivery Options

PES FR 660V 90A 4P Plug with IP55 rating and durable stainless steel construction—ideal for mining and hazardous environments. Built for safety and reliability, featuring easy termination and flameproof repair capabilities.

Description

Product Name/Title: PES FR 660V 90A 4P Plug (270) 4-C 20-23-G (5 Core)

Brand: Ausproof

SKU: RS2271FR

Alternatively Known As: PES 90A 4 Pole Plug, Ex-certified 660V Plug, Flameproof Industrial Plug, Mining Grade Plug

Technical Specifications

Voltage: 660-1,100V
Current Rating: Ex 60 Amp; Non Ex 90 Amp
Material: Grade 304 Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 Tests of 3.2kA for 0.2 seconds
Through Fault Current (Earth): 2 Tests of 1.0kA for 0.2 seconds
AC HV Withstand (Phase): 4.2kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Suitable for 60A and 90A
Plug Weight: 2.6KG
Receptacle Weight: 5.0KG
Dimensions (H x L x W): 200mm x 250mm x 150mm
Weight: 2.6 kg

Key Features

A single solid earth body
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone protection cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified personnel trained in hazardous area electrical equipment is required.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces waste and replacement frequency.
Flameproof repairable design minimizes product disposal and environmental impact.

Warranty Information

Warranty details available upon request from Ausproof.

Available Now

The Ausproof PES FR 660V 90A 4P Plug is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
