Photoelectric Head E51DT1 | Shielded Actuator | NEMA Rated | IP67 Environmental Rating | @Each by Eaton
The Photoelectric Head E51DT1 is designed for precise sensing in industrial automation, featuring a shielded actuator function and NEMA-rated for harsh environments. With an IP67 environmental rating, it ensures reliable performance in dust and water exposure, making it ideal for limit switch applications and machine safety systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Head E51DT1 | Shielded Actuator | NEMA Rated | IP67 Environmental Rating | @Each by Eaton
Brand: Eaton
SKU: E51DT1
Alternatively Known As: E51 Inductive Proximity Sensor Head, Eaton E51DT1 Sensor, NEMA Limit Switch Sensor
Technical Specifications
- Sensing Range: 0.51 inches
- Actuator Function: Shielded
- Frequency Rating: Standard
- Enclosure Material: Plastic
- Environmental Rating: NEMA 3, 3S, 4, 4X, 6, 6P, 12, 13, IP67
- Operating Temperature: -13°F to 158°F
- Weight: 0.1 lb (approx. 0.05 kg)
- Dimensions (H x L x W): 38mm x 35mm x 38mm
- Weight: 0.1 kg
Key Features
- Shielded actuator function for precise sensing
- Standard frequency rating
- Plastic enclosure material
- NEMA rated for harsh environments (NEMA 3, 3S, 4, 4X, 6, 6P, 12, 13)
- IP67 environmental rating for dust and water resistance
- Operating temperature range from -13°F to 158°F
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper sensor alignment and electrical connections.
Applications
- Industrial automation for position sensing
- Limit switch applications in manufacturing
- Machine safety and control systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Energy-efficient sensor operation minimizes power consumption
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Eaton E51DT1 Photoelectric Head is available for immediate purchase, ideal for industrial automation and limit switch applications.
