Photoelectric Proximity Sensor WTB12-3P2461S58 | Background Suppression | 50 mm to 500 mm Sensing Range | IP66, IP67, IP69K Rated | by SICK
The WTB12-3P2461S58 Photoelectric Proximity Sensor is designed for precise object detection in industrial automation, featuring a sensing range of 50 mm to 500 mm and a PinPoint LED visible red light source. With robust IP66, IP67, and IP69K protection ratings, this sensor is built to withstand harsh environments, making it ideal for detecting perforated and shiny objects in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Proximity Sensor WTB12-3P2461S58 | Background Suppression | 50 mm to 500 mm Sensing Range | IP66, IP67, IP69K Rated | by SICK
Brand: SICK
SKU: 1047850
Alternatively Known As: Photoelectric Proximity Sensor, Background Suppression Sensor, SICK Proximity Sensor, Industrial Object Sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 50 mm to 500 mm
- Light source: PinPoint LED visible red light
- Light spot size at 150 mm: 50 mm x 5 mm
- Adjustment: Potentiometer, 5 turns
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 40 mA
- Output type: PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 700 µs
- Switching frequency: 750 Hz
- Protection class: III
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40 °C to +60 °C
- Connection: Male connector M12, 4-pin
- Housing material: Metal with plastic PMMA front screen
- Dimensions (H x L x W): 48.5mm x 42mm x 15.6mm
- Weight: 0.12 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 50 mm to 500 mm
- PinPoint LED visible red light source
- Potentiometer adjustment with 5 turns
- Line-shaped light spot for precise detection
- High switching frequency of 750 Hz
- Robust metal housing with IP66, IP67, and IP69K protection ratings
- Operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Detecting perforated objects
- Detecting objects with position tolerances
- Detecting objects wrapped in film
- Detecting uneven, shiny objects
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable metal housing extends product lifespan, reducing waste
Warranty Information
Warranty details available upon request from the manufacturer.
Available Now
The SICK WTB12-3P2461S58 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
