Photoelectric Proximity Sensor WTB4FP-2216D200A91 | Background Suppression | Adjustable Sensing Range | IP66/IP67 Rated | by SICK
The WTB4FP-2216D200A91 photoelectric proximity sensor is designed for precise object detection in industrial automation. With a sensing range of 4 mm to 100 mm and adjustable switching thresholds, it ensures high accuracy and repeatability. Featuring an IP66/IP67 rated enclosure, this sensor is built to withstand harsh environments, making it ideal for manufacturing processes and distance measurement applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 4 mm to 100 mm, adjustable switching threshold 15 mm to 100 mm
- Distance measuring range: 15 mm to 100 mm with 1 mm resolution
- Repeatability: 0.3 mm to 2.2 mm
- Accuracy: Typically 3.0 mm at 15 to 50 mm distance
- Light source: PinPoint LED, visible red light, wavelength 635 nm
- Beam shape: Point-shaped with 2 mm diameter at 50 mm distance
- Update rate of distance value: 20 ms
- Digital outputs: 2 push-pull (PNP/NPN), max 100 mA output current
- Supply voltage: 10 V DC to 30 V DC
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Connection: Male M8, 4-pin connector
- Housing material: Plastic VISTAL®
- Response time: ≤ 1,000 µs
- Switching frequency: 500 Hz
- Communication interface: IO-Link V1.1, COM2 (38.4 kBaud)
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Adjustable switching threshold from 15 mm to 100 mm
- Sensing range from 4 mm to 100 mm, recommended 30 mm to 60 mm
- Distance value output via IO-Link with 20 ms update rate
- Visible red light PinPoint LED with 635 nm wavelength
- High repeatability and accuracy with resolution of 1 mm
- IP66 and IP67 rated enclosure for harsh environments
- Operating temperature range from -40 °C to +60 °C
- Smart Task function with timestamp and debouncing
- Two individually adjustable push-pull digital outputs (PNP/NPN)
- Robust plastic VISTAL® housing with flat design
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper configuration and connection, especially for IO-Link communication setup.
Applications
- Industrial automation for object detection
- Detecting flat and small objects
- Distance measurement in manufacturing processes
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient operation with low current consumption (25 mA)
- Robust design minimizes environmental impact through durability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WTB4FP-2216D200A91 photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
