Photoelectric Proximity Sensor | Background Suppression | Adjustable Sensing Range | IP66/IP67 Rated | by SICK
The Photoelectric Proximity Sensor WTB4FP-22862120A00 features background suppression and an adjustable sensing range from 4 mm to 220 mm, making it ideal for industrial automation and precise object detection. With a robust IP66/IP67 rated housing and a high switching frequency of up to 1000 Hz, this sensor is built for reliability in demanding environments, ensuring optimal performance in quality control and process monitoring applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 4 mm to 220 mm, adjustable switching threshold 15 mm to 220 mm
- Light source: PinPoint LED, visible red light, wavelength 635 nm
- LED risk group: Free group according to EN 62471
- Response time: ≤ 500 µs
- Switching frequency: 1000 Hz
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 25 mA at 24 V
- Digital outputs: 2 complementary PNP outputs, light/dark switching
- Protection class: III
- Housing material: Plastic VISTAL® with PMMA front screen
- Connection: Male M8, 4-pin connector
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Communication: IO-Link V1.1 with 2.3 ms cycle time
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Adjustable switching threshold from 15 mm to 220 mm
- Sensing range from 4 mm to 220 mm, recommended 40 mm to 140 mm
- PinPoint LED visible red light with 635 nm wavelength
- BluePilot for easy sensing range setting
- IO-Link V1.1 interface for sensor configuration and Smart Task functions
- High switching frequency up to 1000 Hz
- Robust plastic VISTAL® housing with IP66/IP67 protection
- Operating temperature range from -40 °C to +60 °C
- LED indicators for sensing range, power, IO-Link mode, and object detection
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper configuration and secure mounting, especially for IO-Link integration.
Applications
- Industrial automation for object detection
- Background suppression sensing in manufacturing
- Quality control and process monitoring
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source with long service life of 100,000 hours
- Durable design reduces waste and replacement frequency
- Complies with environmental standards including China-RoHS and ECOLAB certification
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WTB4FP-22862120A00 photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
