Photoelectric Proximity Sensor WTB16I-24161120A00 | Background Suppression | Infrared LED | IP66/IP67/IP69 Rated | by SICK
The WTB16I-24161120A00 photoelectric proximity sensor is designed for precise object detection in industrial automation. With a sensing range of 10 mm to 400 mm and an infrared LED light source, it ensures reliable performance. Built for durability with an IP66/IP67/IP69 rating, this sensor is perfect for manufacturing process control and material handling applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 10 mm to 400 mm
- Light source: Infrared LED, wavelength 850 nm
- Light spot size: Ø 12 mm at 800 mm distance
- LED risk group: Free group according to EN 62471
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 30 mA without load at 24 V
- Digital outputs: 2 complementary push-pull (PNP/NPN), light/dark switching
- Switching frequency: up to 1000 Hz
- Response time: ≤ 500 µs
- Protection class: III
- Enclosure rating: IP66, IP67, IP69
- Operating temperature: -40°C to +60°C
- Connection: Male M12, 4-pin connector
- Housing material: Plastic VISTAL®
- Front screen material: Plastic PMMA
- Weight: Approx. 50 g
- Dimensions (H x L x W): 55.7mm x 42mm x 20mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 10 mm to 400 mm with preset switching threshold at 400 mm
- Infrared LED light source with point-shaped light spot of Ø 12 mm at 800 mm
- Long LED service life of 100,000 hours at 25°C
- IO-Link interface for sensor parameter configuration and Smart Task functions
- Dual complementary push-pull digital outputs (PNP/NPN) with light/dark switching
- High switching frequency up to 1000 Hz and fast response time ≤ 500 µs
- Robust plastic VISTAL® housing with IP66, IP67, and IP69 protection ratings
- Wide ambient operating temperature range from -40°C to +60°C
- Shock resistance up to 50 g and vibration resistance from 10 Hz to 2000 Hz
- LED indicators for sensing range, power, IO-Link mode, and object presence status
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper electrical connection and sensor configuration via IO-Link.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Material handling and packaging systems
- Robotics and safety systems requiring precise proximity sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long LED service life reduces waste and replacement frequency
- Energy-efficient LED light source minimizes power consumption
- Robust design reduces environmental impact through durability and reliability
Warranty Information
Warranty details available upon request from manufacturer or authorized distributor.
Available Now
The SICK WTB16I-24161120A00 photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
