Photoelectric Proximity Sensor RT-P1233 | Background Suppression | Infrared LED | IP67 Rated | by SICK
The Photoelectric Proximity Sensor RT-P1233 is designed for precise object detection in industrial automation, featuring a sensing range of 60 mm to 900 mm and a robust IP67-rated housing. With a fast response time of 2 ms and a high switching frequency of 250 Hz, this sensor is perfect for material handling and safety applications, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 60 mm to 900 mm
- Light source: Infrared LED
- Focus angle: 7°
- Light spot size at 500 mm: Ø 20 mm
- Adjustment: Potentiometer, 9 turns
- Supply voltage: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 20 mA
- Switching output: PNP, light switching mode
- Signal voltage PNP HIGH/LOW: Approx. Vs – 0.5 V / 0 V
- Output current max: ≤ 100 mA
- Response time: 2 ms
- Switching frequency: 250 Hz
- Connection type: Cable with M12 male connector, 4-pin, 300 mm
- Circuit protection: Types A, C, D
- Protection class: III
- Housing material: Plastic, ABS
- Enclosure rating: IP67
- Shock and vibration resistance: According to IEC 68
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- MTTFD: 1,525 years
- UL File No.: NRKH.E189383 & NRKH7.E189383
- Dimensions (H x L x W): 99mm x 49mm x 21mm
- Weight: 0.175 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 60 mm to 900 mm
- Infrared LED light source with 7° focus and angle of dispersion
- Potentiometer adjustment with 9 turns for sensitivity tuning
- PNP switching output with light switching mode
- High switching frequency of 250 Hz and fast response time of 2 ms
- Robust plastic ABS housing with IP67 enclosure rating
- Shock and vibration resistant according to IEC 68
- Wide ambient operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Safety and control in manufacturing processes
- ZoneControl applications requiring precise sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable design reduces waste and replacement frequency
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK RT-P1233 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
