Photoelectric Proximity Sensor RT-M1117 | Background Suppression | Infrared LED | IP67 Rated | by SICK
The Photoelectric Proximity Sensor RT-M1117 features advanced background suppression technology and a sensing range of 60 mm to 900 mm, making it ideal for industrial automation and safety control applications. With a fast response time of 2 ms and a robust IP67-rated housing, this sensor ensures reliable performance in challenging environments, perfect for material handling and packaging systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 60 mm to 900 mm
- Light source: Infrared LED
- Focus angle: 7°
- Light spot size: Ø 20 mm at 500 mm distance
- Supply voltage: 21.6 V DC to 250 V DC, 96 to 250 V AC @ 60 Hz, 111 to 250 V AC @ 50 Hz
- Ripple: < 5 V pp
- Current consumption: 10 mA
- Switching output: FET, light switching mode
- Output current max: ≤ 100 mA
- Response time: 2 ms
- Switching frequency: 250 Hz
- Connection type: 4-wire cable, 2 m length
- Circuit protection: Types A, C, D
- Protection class: II
- Housing material: Plastic ABS
- Enclosure rating: IP67
- Shock and vibration resistance: According to IEC 68
- Operating temperature: -40 °C to +40 °C
- Storage temperature: -40 °C to +75 °C
- MTTFD: 552 years
- Dimensions (H x L x W): 99mm x 49mm x 21mm
- Weight: 0.175 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 60 mm to 900 mm
- Infrared LED light source with 7° focus and angle of dispersion
- Potentiometer adjustment with 9 turns for sensitivity tuning
- High switching frequency of 250 Hz and fast response time of 2 ms
- Cable connection with 4-wire, 2 m length
- Robust plastic ABS housing with IP67 enclosure rating
- Shock and vibration resistant according to IEC 68 standards
- Wide operating temperature range from -40 °C to +40 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with photoelectric sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Safety and control in manufacturing processes
- ZoneControl applications requiring precise sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 10 mA current draw
- Durable design reduces waste and replacement frequency
- Complies with China-RoHS environmental standards
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK RT-M1117 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety control applications.
