Photoelectric Proximity Sensor WTB9LC-3P2462A70 | Background Suppression | IP66/IP67/IP69K Rated | by SICK
The WTB9LC-3P2462A70 photoelectric proximity sensor is designed for precise object detection in industrial automation. With a sensing range of 25 mm to 300 mm and a visible red laser light source, it ensures reliable performance in harsh environments. Featuring a fast response time of ≤ 0.5 ms and an IP66/IP67/IP69K protection rating, this sensor is perfect for manufacturing process control and quality inspection systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 25 mm to 300 mm
- Light source: Visible red laser, 650 nm wavelength
- Laser class: 1 (IEC 60825-1)
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP complementary, max 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: up to 1000 Hz
- Connection: Male M12, 4-pin connector
- Protection class: III
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -30 °C to +55 °C (extended)
- Housing material: Plastic VISTAL®, Optics material: PMMA
- Communication interface: IO-Link V1.1, COM2 (38.4 kBaud)
- Dimensions (H x L x W): 52.2mm x 23.6mm x 12.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red laser light source with 650 nm wavelength
- Sensing range from 25 mm to 300 mm
- Rectangular housing design with M3 mounting hole
- IO-Link communication interface V1.1 with COM2 (38.4 kBaud)
- Fast response time ≤ 0.5 ms and switching frequency up to 1000 Hz
- High protection rating IP66, IP67, IP69K for harsh environments
- Complementary PNP switching output with light/dark switching mode
- Laser class 1 safety certified (IEC 60825-1)
- Operating temperature range from -30 °C to +55 °C (extended)
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and IO-Link configuration to ensure proper operation and safety compliance.
Applications
- Industrial automation for detecting small objects
- Manufacturing process control
- Material handling and packaging systems
- Quality control and inspection systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient operation with low current consumption (30 mA)
- Durable IP69K rated housing reduces waste by extending product life
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WTB9LC-3P2462A70 photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
