Photoelectric Proximity Sensor GTB2F-F5141 | Background Suppression | IP67 Rated | 800 Hz Switching Frequency | by SICK
The Photoelectric Proximity Sensor GTB2F-F5141 is designed for precise object detection in industrial automation, featuring a sensing range of 1 mm to 8 mm and a high switching frequency of 800 Hz. With its IP67 rated enclosure, it ensures reliable performance in harsh environments, making it ideal for manufacturing process control and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Minimum detectable object: 0.1 mm
- Sensing range: 1 mm to 8 mm
- Light source: PinPoint LED, visible red light at 660 nm wavelength
- Light spot size: Ø 1 mm at 5 mm distance
- Supply voltage: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 20 mA
- Switching output: PNP, dark switching mode
- Maximum output current: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection type: Cable with M8 3-pin connector, 200 mm length
- Cable material: Plastic PVC, diameter Ø 2.3 mm
- Circuit protection: Types A, C, D
- Housing material: Plastic VISTAL®
- Optics material: Plastic MABS
- Enclosure rating: IP67
- Operating temperature: -20°C to +50°C
- Storage temperature: -40°C to +70°C
- Repeatability: 0.1 mm
- Hysteresis: < 0.3 mm
- Dimensions (H x L x W): 24mm x 3.5mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Rectangular housing design with visible red light
- PinPoint LED light source with 660 nm wavelength
- Sensing range from 1 mm to 8 mm
- Dark switching PNP output
- High switching frequency of 800 Hz
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Robotics and material handling
- Quality control systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 rated housing reduces waste from replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GTB2F-F5141 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
