Photoelectric Proximity Sensor GTB2F-P1311 | Background Suppression | IP67 Rated | 800 Hz Switching Frequency | by SICK
The Photoelectric Proximity Sensor GTB2F-P1311 is designed for precise object detection in industrial automation, featuring background suppression and a high switching frequency of 800 Hz. With an IP67 rated enclosure, it ensures reliable performance in harsh environments, making it ideal for manufacturing process control and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP, light switching mode
- Maximum output current: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection: 3-wire cable, 2 m length, PVC material
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, MABS
- Enclosure rating: IP67
- Operating temperature: -20°C to +50°C
- Storage temperature: -40°C to +70°C
- Minimum detectable object: 0.1 mm
- Light spot size: Ø 3 mm at 8 mm distance
- Wave length: 455 nm
- Dimensions (H x L x W): 24mm x 3.5mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Rectangular housing design with visible blue light emission
- Sensing range up to 15 mm
- PinPoint LED light source with 455 nm wavelength
- High switching frequency of 800 Hz
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging machinery
- Robotics and material handling
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 housing reduces waste by extending product life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GTB2F-P1311 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
