Photoelectric Proximity Sensor IRT-P212C63 | Background Suppression | IP67 Rated | Fast Response Time | by SICK
The IRT-P212C63 Photoelectric Proximity Sensor is designed for industrial automation, featuring background suppression and a sensing range from 60 mm to 900 mm. With an IP67 rated enclosure, it withstands harsh environments while providing a fast response time of 2 ms, making it ideal for pneumatic valve control systems and precise object detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Actuator: Pneumatic, valve supplied separately
- Max. number of sensors: Approx. 30 to 50 depending on configuration
- Logical principle of operation: Single accumulation
- Type of release: Single release, block (slug) release
- Focus: 7°
- Light spot size at 500 mm: Ø 20 mm
- Adjustment: Potentiometer, 9 turns
- Supply voltage UB: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 20 mA
- Switching output: PNP
- Signal voltage PNP HIGH/LOW: Approx. VS – 0.5 V / 0 V
- Output current Imax: ≤ 100 mA
- Response time: 2 ms
- Switching frequency: 250 Hz
- Connection type: Male connector M12, 4-pin
- Connection type for daisy chain: Cable with female connector, M12, 4-pin 2 m
- Circuit protection: Types A, C, D
- Protection class: III
- Housing material: Plastic, ABS
- Enclosure rating: IP67
- Shock and vibration resistance: According to IEC 68
- Ambient operating temperature: –40 °C to +60 °C
- Ambient temperature, storage: –40 °C to +75 °C
- UL File No.: NRKH.E189383 & NRKH7.E189383
- Mode of operation solenoid valve: HIGH to Drive
- Connection type solenoid valve: Cable with 9.4 mm DIN valve connection
- Dimensions (H x L x W): 99mm x 49mm x 21mm
- Weight: 0.175 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 60 mm to 900 mm
- Infrared LED light source with 7° angle of dispersion
- Potentiometer adjustment with 9 turns for sensitivity tuning
- IP67 rated enclosure for dust and water protection
- Shock and vibration resistant according to IEC 68
- PNP switching output with max output current ≤ 100 mA
- Fast response time of 2 ms and switching frequency of 250 Hz
- Male M12 4-pin connector with daisy chain cable option
- Operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician familiar with photoelectric sensors and pneumatic valve systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Pneumatic valve control systems
- ZoneControl applications requiring precise sensing
- Harsh environments requiring IP67 rated sensors
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP67 housing extends product life and reduces waste
- Supports automation that can optimize resource use and reduce emissions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK IRT-P212C63 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and pneumatic control applications.
