Photoelectric Proximity Sensor RT-B1117 | Background Suppression | IP67 Rated | Fast Response Time | by SICK
The RT-B1117 Photoelectric Proximity Sensor is designed for precise object detection in industrial automation, featuring a sensing range of 60 mm to 900 mm and an infrared LED light source. With an IP67 rated enclosure for dust and water protection, this sensor ensures reliable performance in challenging environments, making it ideal for material handling, robotics, and manufacturing process control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 60 mm to 900 mm
- Light source: Infrared LED
- Focus angle: 7°
- Light spot size at 500 mm: Ø 20 mm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP and NPN
- Switching mode: Light switching
- Output current max: ≤ 100 mA
- Response time: 2 ms
- Switching frequency: 250 Hz
- Connection type: 4-wire cable, 2 m length
- Protection class: III
- Enclosure rating: IP67
- Housing material: Plastic, ABS
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Shock and vibration resistance: According to IEC 68
- Dimensions (H x L x W): 99mm x 49mm x 21mm
- Weight: 0.175 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 60 mm to 900 mm
- Infrared LED light source with 7° focus and angle of dispersion
- Adjustable potentiometer with 9 turns for sensitivity tuning
- IP67 rated enclosure for dust and water protection
- Shock and vibration resistant according to IEC 68
- Supports both PNP and NPN switching outputs
- Fast response time of 2 ms and switching frequency of 250 Hz
- Wide ambient operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with photoelectric sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Robotics and manufacturing process control
- ZoneControl applications requiring precise sensing
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable ABS plastic housing reduces need for frequent replacements
- Long operational life with MTTFD of 1,525 years enhances sustainability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK RT-B1117 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
