Photoelectric Proximity Sensor RTF-P3117 | Background Suppression | IP67 Rated | Fast Response Time | by SICK
The RTF-P3117 Photoelectric Proximity Sensor is designed for industrial automation, featuring a sensing range of 60 mm to 900 mm and an infrared LED light source. With an IP67 rated enclosure for dust and water protection, this sensor ensures reliable performance in challenging environments. Ideal for material handling and safety control applications, it offers a fast response time of 2 ms and adjustable sensitivity for precise detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 60 mm to 900 mm
- Light source: Infrared LED
- Light spot size: Ø 20 mm at 500 mm distance
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP, max output current ≤ 100 mA
- Switching mode: Light/dark switching
- Response time: 2 ms
- Switching frequency: 250 Hz
- Adjustment: Potentiometer, 9 turns
- Connection type: 4-wire cable, 2 m length
- Protection class: III
- Enclosure rating: IP67
- Housing material: Plastic, ABS
- Operating temperature range: -40 °C to +60 °C
- Storage temperature range: -40 °C to +75 °C
- Shock and vibration resistance: According to IEC 68
- Dimensions (H x L x W): 99mm x 49mm x 21mm
- Weight: 0.175 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range from 60 mm to 900 mm
- Infrared LED light source with 7° focus and angle of dispersion
- Adjustable potentiometer with 9 turns for sensitivity tuning
- IP67 rated enclosure for dust and water protection
- Robust plastic ABS housing with shock and vibration resistance
- Light/dark switching mode with PNP output
- Fast response time of 2 ms and switching frequency of 250 Hz
- Off delay time function adjustable from 0 to 5 seconds
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Safety and control in manufacturing processes
- ZoneControl applications requiring precise sensing
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable design reduces replacement frequency and waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK RTF-P3117 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety control applications.
