Photoelectric Proximity Sensor GTB2F-N1141 | Background Suppression | IP67 Rated | Fast Response Time | by SICK
The Photoelectric Proximity Sensor GTB2F-N1141 is designed for precise object detection in industrial automation, featuring a sensing range of 1 mm to 8 mm and a fast response time of under 0.625 ms. With its IP67 rated enclosure, this sensor is perfect for harsh environments, ensuring reliable performance in manufacturing and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 1 mm to 8 mm
- Light source: PinPoint LED, visible red light at 660 nm wavelength
- Minimum detectable object: 0.1 mm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: NPN, light switching mode
- Output current max: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection type: 3-wire cable, 2 m length, PVC material
- Enclosure rating: IP67
- Operating temperature range: -20 °C to +50 °C
- Storage temperature range: -40 °C to +70 °C
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, MABS
- Repeatability: 0.1 mm
- Hysteresis: < 0.3 mm
- Dimensions (H x L x W): 24mm x 3.5mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Rectangular housing design with visible red light
- PinPoint LED light source with 660 nm wavelength
- Sensing range from 1 mm to 8 mm
- High switching frequency of 800 Hz
- IP67 rated enclosure for dust and water protection
- Cable connection with 3-wire, 2 m PVC cable
- Fast response time under 0.625 ms
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Quality assurance systems
- Robotics and material handling
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 housing reduces waste by extending product life
- RoHS compliant, reducing hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK GTB2F-N1141 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
