Photoelectric Proximity Sensor HTB18-L5C2AH | Background Suppression | IP67 & IP69K Rated | by SICK
The HTB18-L5C2AH Photoelectric Proximity Sensor is designed for industrial automation, featuring a sensing range of 5 mm to 300 mm and a fast response time of ≤ 0.5 ms. With its robust IP67 and IP69K rated housing, this sensor ensures reliable performance in harsh environments, making it ideal for manufacturing process control and safety monitoring in machinery.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 300 mm
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Housing design: Hybrid with M18 thread diameter
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with male micro connector, 4-pin, 300 mm
- Cable material: Plastic, PVC
- Protection class: II
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light with PinPoint LED light source
- Sensing range up to 300 mm
- Hybrid housing design with M18 thread diameter
- IP67 and IP69K rated for dust and water protection
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- MOSFET switching output with light switching mode
- Wide supply voltage range: 21.6 V DC to 250 V DC and 96 V AC to 250 V AC
- Cable with male micro connector, 4-pin, 300 mm length
- Robust plastic VISTAL® housing and PMMA optics material
- Operating temperature range from -40 °C to +65 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient MOSFET switching output
- Durable IP67/IP69K rated housing reduces replacement frequency and waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-L5C2AH Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
