Photoelectric Proximity Sensor HTB18-L5B2AH | Background Suppression | IP67 & IP69K Rated | by SICK
The HTB18-L5B2AH Photoelectric Proximity Sensor is designed for precise object detection in industrial automation, featuring a sensing range of 5 mm to 300 mm and a fast response time of ≤ 0.5 ms. With its durable IP67 and IP69K rated housing, this sensor is perfect for manufacturing process control and safety monitoring in machinery, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range max.: 5 mm to 300 mm
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Light spot size: 7 mm at 300 mm distance
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable with male micro connector, 4-pin, 150 mm
- Housing material: Plastic VISTAL®, optics material: Plastic PMMA
- Protection class: II
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light with PinPoint LED light source
- Sensing range from 5 mm to 300 mm
- Hybrid housing design with M18 thread diameter
- IP67 and IP69K rated for dust and water protection
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- MOSFET switching output with light switching mode
- Wide supply voltage range: 21.6 V DC to 250 V DC and 96 V AC to 250 V AC
- Cable with male micro connector, 4-pin, 150 mm length
- Operating temperature range from -40 °C to +65 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient MOSFET output
- Durable IP67/IP69K rated housing reduces waste from replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-L5B2AH Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
