Photoelectric Proximity Sensor | Background Suppression | M18 Hybrid Design | IP67 Rated | by SICK
The Photoelectric Proximity Sensor ZTB18-2AB5B1D02 features advanced background suppression technology, making it ideal for industrial automation and manufacturing process control. With a sensing range of 5 mm to 50 mm and an infrared PinPoint LED light source, this sensor ensures precise object detection. Its robust IP67 rated housing provides excellent dust and water protection, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Housing design: Hybrid with M18 thread diameter
- Sensing range: 5 mm to 50 mm
- Light source: Infrared PinPoint LED, wavelength 850 nm
- Light spot size: Ø 8 mm at 100 mm distance
- Supply voltage: 10 V DC to 30 V DC with ripple < 10%
- Current consumption: ≤ 15 mA
- Switching output: Push-pull PNP/NPN with light and dark switching
- Output current max: 100 mA
- Response time: ≤ 1 ms
- Switching frequency: 500 kHz
- Connection: Cable with male M8 4-pin connector, 150 mm length
- Cable material: Plastic PVC, conductor cross section 0.13 mm²
- Protection class: III
- Housing material: Plastic ABS, optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -40 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- UL File No.: E189383
- Dimensions (H x L x W): 35mm x 22mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Hybrid housing design with M18 thread diameter
- Sensing range from 5 mm to 50 mm
- Infrared PinPoint LED light source with 850 nm wavelength
- Push-pull PNP/NPN switching outputs with light and dark switching modes
- High switching frequency of 500 kHz and response time ≤ 1 ms
- Cable with male M8 4-pin connector, 150 mm length
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40 °C to +55 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging machinery
- Material handling systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67 rated housing reduces environmental waste by extending product life
- Compliance with China-RoHS ensures reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK ZTB18-2AB5B1D02 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
