Photoelectric Proximity Sensor | Background Suppression & MultiMode Operation | 650mm Sensing Range | by SICK
The Photoelectric Proximity Sensor WTM12L-1H161820A00 features advanced background suppression and MultiMode operation, making it ideal for detecting small and high-speed objects in industrial settings. With a robust design and IP66, IP67, and IP69 ratings, this sensor ensures high accuracy and reliability, perfect for automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 49.5mm x 43.1mm x 15.6mm
- Weight: 0.132 kg
Key Features
- Photoelectric proximity sensor with background and foreground suppression
- MultiMode operation with 6 selectable modes including two-point teach-in and application select
- Sensing range from 0 mm to 650 mm depending on mode
- Adjustable switching thresholds for background and foreground suppression
- Visible red laser light source with ellipse-shaped light spot
- High accuracy distance measurement with 0.1 mm resolution
- IO-Link communication for sensor parameter configuration and Smart Task functions
- Robust metal zinc diecast housing with IP66, IP67, and IP69 protection ratings
- LED indicators for mode, power, IO-Link status, and object detection
- High shock and vibration resistance suitable for industrial environments
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure proper configuration and safety compliance.
Applications
- Detecting small objects
- Detection of objects moving at high speeds
- Detecting flat objects
- Detecting uneven, shiny objects
- Detection of poorly remitting and tilted objects
- Detecting perforated objects
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Complies with AS/NZS 60947-5-2 for electrical equipment safety
Environmental Benefits
- Long average service life of 50,000 hours reduces waste and replacement frequency
- Energy-efficient operation with low current consumption (≤ 14 mA)
- Robust design minimizes environmental impact through durability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WTM12L-1H161820A00 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
