Photoelectric Proximity Sensor WTB4FP-213111A0ZZZ | Background Suppression | MultiPulse Technology | IP66 & IP67 Rated | by SICK
The WTB4FP-213111A0ZZZ Photoelectric Proximity Sensor is designed for precision object detection in industrial automation. With a sensing range of 28 mm to 165 mm and advanced MultiPulse technology, it ensures reliable performance. Its robust IP66 and IP67 rated housing makes it ideal for harsh environments, while the PinPoint LED light source enhances visibility. Perfect for manufacturing process control and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Proximity Sensor WTB4FP-213111A0ZZZ | Background Suppression | MultiPulse Technology | IP66 & IP67 Rated | by SICK
Brand: SICK
SKU: 1125740
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, MultiPulse photoelectric sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression and MultiPulse
- Sensing range: 28 mm to 165 mm
- Light source: PinPoint LED, visible red light, 635 nm wavelength
- Smallest detectable object: 0.2 mm at 130 mm distance
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 25 mA at 24 V
- Output type: Push-pull PNP/NPN digital output
- Response time: ≤ 0.1 s
- Switching frequency: 10 Hz
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature range: -40 °C to +60 °C
- Housing material: Plastic VISTAL®
- Connection: M8, 3-pin connector
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression and MultiPulse technology
- Sensing range from 28 mm to 165 mm with high precision
- PinPoint LED visible red light with a wavelength of 635 nm
- Smallest detectable object size of 0.2 mm at 130 mm distance
- Robust plastic VISTAL® housing with IP66 and IP67 protection ratings
- LED indicators for power and object detection status
- High shock and vibration resistance
- Self-monitoring sensor with fixed sensing range
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and sensor alignment for optimal performance and safety.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Robotics and safety monitoring
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient operation with low current consumption
- Robust design minimizes environmental impact through durability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WTB4FP-213111A0ZZZ Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
