Photoelectric Proximity Sensor GTB2F-F1141 | Background Suppression | PNP Output | IP67 Rated | by SICK
The GTB2F-F1141 Photoelectric Proximity Sensor is designed for precise object detection in industrial automation. With a background suppression feature and a fast response time of under 0.625 ms, it ensures reliable performance in manufacturing and quality assurance applications. Its IP67 rated enclosure provides excellent dust and water protection, making it ideal for challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 20 mA
- Switching output: PNP
- Switching mode: Dark switching
- Output current max: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection type: 3-wire cable, 2 m length
- Cable material: Plastic, PVC
- Cable diameter: 2.3 mm
- Circuit protection: Types A, C, D
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, MABS
- Enclosure rating: IP67
- Operating temperature: -20°C to +50°C
- Storage temperature: -40°C to +70°C
- Repeatability: 0.1 mm
- Hysteresis: < 0.3 mm
- Light source: PinPoint LED, 660 nm wavelength
- Light spot size: Ø 1 mm at 5 mm distance
- Dimensions (H x L x W): 24mm x 3.5mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Rectangular housing design with visible red light emission
- Minimum detectable object size of 0.1 mm
- Sensing range from 1 mm to 8 mm
- PinPoint LED light source with 660 nm wavelength
- Dark switching mode with PNP output
- High switching frequency of 800 Hz and fast response time under 0.625 ms
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Quality assurance systems
- Material handling and packaging
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 rated housing reduces waste from replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GTB2F-F1141 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
