Photoelectric Proximity Sensor WTV4FE-5G3111A0ZZZ | Background Suppression | V-Optics Technology | IP66/IP67 Rated | by SICK
The WTV4FE-5G3111A0ZZZ Photoelectric Proximity Sensor is designed for precise object detection in industrial automation. With a sensing range of 4 mm to 22 mm and advanced background suppression technology, it ensures reliable performance even in challenging environments. Featuring a robust IP66/IP67 rated housing, this sensor operates efficiently in temperatures from -40 °C to +60 °C, making it ideal for manufacturing and production lines.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression and V-optics
- Sensing range: 4 mm to 22 mm
- Light source: PinPoint LED, visible red light, wavelength 635 nm
- Light spot size at 30 mm: 0.5 mm x 1.9 mm
- LED risk group: Free group according to EN 62471 and IEC 62471
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 25 mA without load at 24 V
- Output type: Push-pull PNP/NPN light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1000 Hz
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Cable: 3-wire, 3 m length, PVC insulated
- Housing material: Plastic VISTAL®, front screen PMMA
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression and V-optics
- Sensing range from 4 mm to 22 mm
- PinPoint LED visible red light with rectangular light spot
- LED green operating indicator and LED yellow object presence indicator
- Preset sensing range of 22 mm
- Detects smallest object size of 0.1 mm at 30 mm distance
- High switching frequency of 1000 Hz and fast response time ≤ 500 µs
- Protection class III with reverse polarity, overcurrent, and short-circuit protection
- Robust IP66/IP67 rated housing suitable for harsh environments
- Wide ambient operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper wiring, mounting, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Background suppression sensing in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient operation with low current consumption (≤ 25 mA)
- Robust design minimizes environmental impact through durability and reliability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK WTV4FE-5G3111A0ZZZ Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
