Photoelectric Proximity Sensor GRTE18S-P231X | IP67 Rated | 500 Hz Switching Frequency | Red Light Source | by SICK
The Photoelectric Proximity Sensor GRTE18S-P231X is designed for precise object detection in industrial automation. With a robust IP67 rated enclosure, it features a high switching frequency of 500 Hz and a visible red light source for enhanced visibility. Ideal for manufacturing process control and robotics, this sensor ensures reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Proximity Sensor GRTE18S-P231X | IP67 Rated | 500 Hz Switching Frequency | Red Light Source | by SICK
Brand: SICK
SKU: 1059440
Alternatively Known As: Photoelectric proximity sensor, M18 photoelectric sensor, Red light proximity sensor, Industrial object sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP, light switching mode
- Output current max: ≤ 100 mA
- Switching frequency: 500 Hz
- Response time: < 1,000 µs
- Protection class: III
- Enclosure rating: IP67
- Housing material: Metal, nickel-plated brass and ABS
- Optics material: Plastic, PMMA
- Connection type: Connector M12, 3-pin
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Circuit protection: Types A, B, D
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 18mm x 38.1mm x 18mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Visible red light with PinPoint LED light source
- Radial, fully flush optical axis
- Sensing range from 5 mm to 100 mm
- Potentiometer adjustment with 270° rotation
- LED indicators for power and object detection
- Robust metal housing with nickel-plated brass and ABS
- IP67 rated enclosure for dust and water protection
- Connector M12, 3-pin connection
- High switching frequency of 500 Hz
- Response time less than 1,000 µs
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Robotics and assembly lines
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable construction minimizes waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK GRTE18S-P231X Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
