Photoelectric Proximity Sensor HTB18-M5B2AB | Background Suppression | IP67 & IP69K Rated | by SICK
The HTB18-M5B2AB Photoelectric Proximity Sensor is designed for industrial automation, featuring a sensing range of 5 mm to 150 mm and background suppression technology. With a fast response time of ≤ 0.5 ms and a robust IP67/IP69K rating, this sensor is perfect for object detection and safety monitoring in harsh environments, ensuring reliable performance in manufacturing and material handling applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 150 mm standard, up to 300 mm max
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Housing design: Hybrid with M18 thread diameter
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, dark switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with male micro connector, 4-pin, 150 mm
- Protection class: II
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 46mm x 34mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light with PinPoint LED
- Sensing range from 5 mm to 150 mm (standard) and up to 300 mm (max)
- Hybrid housing design with M18 thread diameter
- Dark switching MOSFET output with max 100 mA output current
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- High protection rating IP67 and IP69K for harsh environments
- Wide operating temperature range from -40 °C to +65 °C
- Cable with male micro connector, 4-pin, 150 mm length
- Complies with electromagnetic compatibility EN 60947-5-2
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment, secure mounting, and correct electrical connections according to industrial safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation with low current consumption (≤ 10 mA)
- Durable IP67/IP69K rated housing reduces waste by extending product life
- Complies with China-RoHS environmental standards
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-M5B2AB Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
