Photoelectric Proximity Sensor HTE18-K4A2AB | NPN Output | IP67 & IP69K Rated | by SICK
The HTE18-K4A2AB Photoelectric Proximity Sensor is designed for precise object detection in industrial automation. With a sensing range of 10 mm to 200 mm and a response time of ≤ 0.5 ms, it ensures quick and reliable performance. Ideal for manufacturing process control and safety monitoring, this sensor features a durable IP67 and IP69K rated housing, making it perfect for harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor, energetic
- Sensing range: 10 mm to 200 mm (max 5 mm to 600 mm)
- Light source: PinPoint LED, visible red light, wavelength 631 nm
- Switching output: NPN, dark switching and alarm output
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Cable material: Plastic, PVC
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Electromagnetic compatibility: EN 60947-5-2
- Dimensions (H x L x W): 49mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Hybrid housing design with blue color
- Sensing range from 10 mm to 200 mm (max 5 mm to 600 mm)
- Visible red light with PinPoint LED light source
- Light spot size 10 mm x 18 mm at 500 mm distance
- Adjustment potentiometer for sensitivity
- Switching output: NPN, dark switching and alarm output
- Response time ≤ 0.5 ms and switching frequency 1,000 Hz
- Male connector M12, 4-pin with plastic PVC cable
- Circuit protection and protection class III
- Housing made of plastic VISTAL® and optics made of PMMA
- Enclosure rating IP67 and IP69K for harsh environments
- Operating temperature range from -40 °C to +70 °C
- Complies with EMC standards EN 60947-5-2
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with photoelectric sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67 and IP69K rated housing reduces waste by extending product life
- Complies with China-RoHS environmental standards
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HTE18-K4A2AB Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
