Photoelectric Proximity Sensor | Infrared LED | IP67 Rated | 2mm to 300mm Sensing Range | by SICK
The Photoelectric Proximity Sensor is designed for industrial automation, featuring an infrared LED light source with a sensing range of 2mm to 300mm. With an IP67 rating for dust and water protection, this robust sensor is perfect for detecting various object types in manufacturing processes, ensuring high reliability and performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 38 mA at 24 V without load
- Output: 1 PNP digital output, max 100 mA
- Response time: ≤ 1 ms
- Switching frequency: 500 Hz
- Protection class: III
- Enclosure rating: IP67
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- Cable with M8 3-pin connector, 500 mm length
- Housing material: Anodised aluminum
- Front screen material: PMMA
- Cable material: PVC
- Connector material: PVC or TPU
- Dimensions (H x L x W): 17mm x 842mm x 20mm
- Weight: 0.31 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Sensing range from 2 mm to 300 mm, optimal 2 mm to 45 mm
- Infrared LED light source with 850 nm wavelength
- Point-shaped light spot size 27 mm x 29 mm at 45 mm distance
- 8 beams with 106 mm beam separation
- LED indicators for power and object detection status
- Robust metal aluminum anodised housing with PMMA front screen
- IP67 rated for dust and water protection
- Operating temperature range from -40 °C to +60 °C
- High shock and vibration resistance
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Detecting flat, perforated, uneven, and shiny objects
- Position tolerance detection in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient LED light source minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK RSB1-0842H106050PZ2DZZZZZZ photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
