Photoelectric Proximity Sensor | PNP Output | IP67 Rated | Fast Response Time | by SICK
The Photoelectric Proximity Sensor ZTE18-4FZ3A8 is designed for industrial automation, featuring a sensing range of up to 740 mm and a fast response time of ≤ 1 ms. With an IP67 rating for dust and water protection, this sensor is perfect for manufacturing process control and safety detection in machinery, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor, energetic
- Sensing range max.: 0 mm to 740 mm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 15 mA
- Switching output: PNP, dark switching
- Output current max.: 100 mA
- Response time: ≤ 1 ms
- Switching frequency: 500 kHz
- Connection type: Male connector M8, 4-pin
- Circuit protection: A, B, D
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Operating temperature: –40 °C to +55 °C
- Storage temperature: –40 °C to +70 °C
- Dimensions (H x L x W): 41mm x 34mm x 14mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Visible red light LED with 625 nm wavelength
- Sensing range up to 740 mm
- Hybrid housing design with blue color
- M18 mounting system for head or base installation
- Fast response time of ≤ 1 ms
- High switching frequency of 500 kHz
- PNP switching output with dark switching mode
- IP67 rated enclosure for dust and water protection
- Wide operating temperature range from –40 °C to +55 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Material handling and conveyor systems
- Safety and presence detection in machinery
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with ≤ 15 mA current draw
- Durable ABS and PMMA plastic housing reduces material waste
- Long operational life reduces replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK ZTE18-4FZ3A8 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
