Photoelectric Proximity Sensor WTB12-3P2441S59 | Background Suppression | 50-100 mm Sensing Range | IP66/IP67/IP69K Rated | by SICK
The WTB12-3P2441S59 Photoelectric Proximity Sensor is designed for precise object detection in industrial automation. With a sensing range adjustable from 55 mm to 100 mm and a robust metal housing rated IP66/IP67/IP69K, it ensures reliable performance in harsh environments. Ideal for manufacturing process control and safety monitoring, this sensor features a fast response time of ≤ 250 µs and a high switching frequency of 2,000 Hz.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Proximity Sensor WTB12-3P2441S59 | Background Suppression | 50-100 mm Sensing Range | IP66/IP67/IP69K Rated | by SICK
Brand: SICK
SKU: 1056725
Alternatively Known As: Photoelectric Proximity Sensor, Background Suppression Sensor, SICK Proximity Sensor, Industrial Object Sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range max.: 50 mm to 100 mm, preset at 55 mm
- Light source: LED, visible red light at 640 nm wavelength
- Light spot size: Ø 2 mm at 60 mm distance
- Adjustment: Potentiometer with 5 turns
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 45 mA
- Output type: PNP, light switching mode
- Signal voltage PNP HIGH/LOW: > Uv - 2.9 V / 0 V <= 1.5 V
- Output current max: ≤ 100 mA
- Response time: ≤ 250 µs
- Switching frequency: 2,000 Hz
- Delay time: One shot, 1.2 ms delay
- Protection class: III
- Circuit protection: A, C, D
- Housing: Metal with plastic PMMA front screen
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: –40 °C to +60 °C
- Storage temperature: –40 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.13 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Sensing range preset at 55 mm, adjustable up to 100 mm
- Visible red LED light source with 640 nm wavelength
- Minimum detectable object size of Ø 0.4 mm
- Potentiometer adjustment with 5 turns
- High switching frequency of 2,000 Hz and fast response time ≤ 250 µs
- Robust metal housing with IP66, IP67, and IP69K protection ratings
- Operating temperature range from –40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in machinery
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable construction minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK WTB12-3P2441S59 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
