Photoelectric Proximity Sensor WTB16P-2416N420A00 | Background Suppression | Adjustable Sensing Range | IO-Link Enabled | by SICK
The WTB16P-2416N420A00 Photoelectric Proximity Sensor is designed for precise object detection in industrial automation. With a sensing range adjustable from 100 mm to 1600 mm and a PinPoint LED light source, it ensures reliable performance in various applications. Its robust IP66, IP67, and IP69 rated enclosure makes it perfect for harsh environments, while the IO-Link interface allows for easy configuration and smart task functions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 10 mm to 1600 mm, adjustable switching threshold 100 mm to 1600 mm
- Light source: PinPoint LED, visible red light, 635 nm wavelength
- Light spot size: Ø 6 mm at 500 mm distance
- Response time: ≤ 2.5 ms
- Switching frequency: 200 Hz
- Output type: Push-pull PNP/NPN, dark switching
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 30 mA without load
- Protection class: III
- Enclosure rating: IP66, IP67, IP69
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 2000 Hz
- Communication: IO-Link V1.1, COM2 (38.4 kBaud)
- Housing material: Plastic VISTAL®
- Front screen material: Plastic PMMA
- Connection: Male M12, 4-pin connector
- Dimensions (H x L x W): 55.7mm x 42mm x 20mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Adjustable sensing range from 100 mm to 1600 mm
- PinPoint LED visible red light with 635 nm wavelength
- BluePilot for easy sensing range adjustment
- IO-Link interface for sensor configuration and Smart Task functions
- High shock and vibration resistance
- IP66, IP67, and IP69 rated enclosure for harsh environments
- Reverse polarity, overcurrent, and short-circuit protected outputs
- Long LED service life of 100,000 hours at 25°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper configuration and safety compliance.
Applications
- Industrial automation for object detection
- Material handling and conveyor systems
- Packaging machinery
- Quality control and inspection systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long service life reduces waste and replacement frequency
- Energy-efficient LED light source minimizes power consumption
- Robust design reduces environmental impact from sensor failures
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WTB16P-2416N420A00 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
