Photoelectric Proximity Sensor WTB4FT-22811120ZZZ | Background Suppression | Adjustable Sensing Range | IP66/IP67 Rated | by SICK
The WTB4FT-22811120ZZZ photoelectric proximity sensor is designed for precise object detection in industrial automation. With an adjustable sensing range from 7 mm to 120 mm and a robust IP66/IP67 rating, it excels in harsh environments. Featuring a visible red PinPoint LED light source and fast response time, this sensor is perfect for detecting various object types, ensuring reliable performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression, DoubleLine
- Sensing range: 7 mm to 120 mm adjustable, recommended 30 mm to 80 mm
- Light source: PinPoint LED, visible red light at 635 nm wavelength
- Light spot size: 1.2 mm x 17 mm at 50 mm distance
- Response time: ≤ 1,000 µs, switching frequency up to 500 Hz
- Outputs: 2 complementary PNP outputs, light/dark switching
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 25 mA without load
- Protection class: III
- Housing material: Plastic VISTAL®, front screen PMMA
- Connection: Male M8, 4-pin connector
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 Hz to 1,000 Hz, amplitude 1 mm
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression and DoubleLine technology
- Sensing range adjustable from 7 mm to 120 mm with recommended range 30 mm to 80 mm
- Visible red PinPoint LED light source with line-shaped dual light spots
- BluePilot for easy sensing range adjustment
- High immunity to ambient light up to 50,000 lx
- Robust plastic VISTAL® housing with IP66/IP67 protection
- Fast response time ≤ 1,000 µs and switching frequency up to 500 Hz
- Complementary PNP outputs with light/dark switching modes
- Wide operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure correct sensor alignment, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Detecting flat, shiny, perforated, or film-wrapped objects
- Use in harsh environments requiring IP66/IP67 protection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient operation with low current consumption (≤ 25 mA)
- Robust design minimizes environmental impact through durability and resistance to cleaning agents
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK WTB4FT-22811120ZZZ photoelectric proximity sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
