Photoelectric Proximity Sensor WTV2S-2P3285 | Background Suppression | IP67 Rated | Fast Response Time | by SICK
The WTV2S-2P3285 Photoelectric Proximity Sensor is designed for precise object detection, featuring background suppression and V-optics technology. With a sensing range of 4 mm to 30 mm and a fast response time of under 0.5 ms, it's perfect for detecting small, shiny, or transparent objects in industrial automation applications. Its durable IP67 rated housing ensures reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression, V-optics
- Sensing range: 4 mm to 30 mm (max 36 mm)
- Light source: Visible blue LED, wavelength 445 nm
- Light spot size: 2 mm x 3 mm at 10 mm distance
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP, max output current ≤ 50 mA
- Response time: < 0.5 ms
- Switching frequency: 1000 Hz
- Connection: Cable with M8 male connector, 4-pin, 200 mm length
- Cable material: Plastic PVC, diameter 3 mm
- Housing material: Plastic ABS/PC
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25 °C to +50 °C
- Storage temperature: -40 °C to +75 °C
- Circuit protection: A, B, D types
- UL File No.: NRKH.E181493
- Dimensions (H x L x W): 21.8mm x 13.5mm x 7.7mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression and V-optics
- Rectangular housing design with visible blue light LED
- Sensing range from 4 mm to 30 mm, max 36 mm
- Light spot size 2 mm x 3 mm at 10 mm distance
- Cable (Teach-in) adjustment
- IP67 rated enclosure for dust and water protection
- Fast response time under 0.5 ms and switching frequency of 1000 Hz
- PNP switching output with max output current ≤ 50 mA
- Wide supply voltage range from 10 V DC to 30 V DC
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with photoelectric sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Detecting small objects
- Detecting uneven, shiny objects
- Detecting objects wrapped in film
- Detecting transparent objects
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 rated housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WTV2S-2P3285 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
