Photoelectric Retro-Reflective Sensor | 0.8m Sensing Range | PNP Output | IP66/IP67 Rated | by SICK
The Photoelectric Retro-Reflective Sensor WL12G-3P2472S03 is designed for industrial automation, featuring a sensing range of up to 0.8m and a robust IP66/IP67 rating for harsh environments. With a visible red light LED and a high switching frequency of 1,500 Hz, this sensor is perfect for detecting transparent objects and ensuring reliable performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor without reflector minimum distance
- Sensing range max.: 0 to 0.8 m
- Polarisation filter: Yes
- Light source: LED, visible red light, wavelength 640 nm
- Light spot size at 0.8 m: Ø 14.5 mm
- Adjustment: Single teach-in button
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 30 mA
- Protection class: III
- Output type: PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Circuit protection: A, C, D
- Housing: Metal, zinc diecast
- Front screen: Plastic, PMMA
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP66, IP67
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 0.8 m on reflective tape Diamond Grade
- Polarisation filter included
- Visible red light LED with 640 nm wavelength
- Single teach-in button for sensitivity adjustment
- Light/dark switching with PNP output
- High switching frequency of 1,500 Hz
- Robust metal zinc diecast housing with IP66/IP67 rating
- Operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Detecting transparent objects
- Use in harsh environments requiring IP66/IP67 protection
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable construction minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK WL12G-3P2472S03 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
