Photoelectric Retro-Reflective Sensor WL12L-2B530 | 18m Sensing Range | Laser Light Source | IP67 & IP69K Rated | by SICK
The WL12L-2B530 Photoelectric Retro-Reflective Sensor is designed for high-speed object detection in industrial automation. With a sensing range of up to 18 meters and a visible red laser light source, it ensures precise detection without the need for a reflector. Built with a robust metal housing and IP67/IP69K protection ratings, this sensor is perfect for small object detection in manufacturing lines, providing reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Laser sensor, Object detection sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor without reflector minimum distance (autocollimation/coaxial optics)
- Sensing range max.: 0 m to 18 m
- Polarisation filter: Yes
- Light source: Laser, visible red light, wavelength 650 nm
- Light spot size at 300 mm: Ø 0.8 mm
- Laser class: 2
- Adjustment: Potentiometer
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 55 mA
- Protection class: III
- Output type: PNP/NPN selectable
- Switching mode: Light switching, Dark switching selectable
- Output current max: ≤ 100 mA
- Response time: ≤ 200 µs
- Switching frequency: 2,500 Hz
- Circuit protection: Types A, C, D
- Housing material: Metal
- Front screen material: Plastic, PMMA
- Connection: Plug, M12, 5-pin
- Enclosure rating: IP67, IP69K
- Operating temperature: -10 °C to +50 °C
- Storage temperature: -25 °C to +75 °C
- Dimensions (H x L x W): 49mm x 41.5mm x 15mm
- Weight: 0.13 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 18 meters without reflector
- Polarisation filter included
- Visible red laser light source with 650 nm wavelength
- Focusable from 300 mm to infinite distance
- Selectable light/dark switching modes via control cable
- High switching frequency of 2,500 Hz
- Robust metal housing with IP67 and IP69K protection ratings
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- High-speed object detection
- Small object detection in manufacturing lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient laser technology reduces power consumption
- Durable metal housing extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WL12L-2B530 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
