Photoelectric Retro-Reflective Sensor WL12-3P2451 | 2m Sensing Range | IP66/IP67/IP69K Rated | by SICK
The Photoelectric Retro-Reflective Sensor WL12-3P2451 is designed for precise object detection in industrial automation, featuring a sensing range of up to 2 meters without a reflector. With a robust IP66/IP67/IP69K rating and a visible red LED light source, this sensor is perfect for harsh environments, ensuring reliable performance in manufacturing lines and safety systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK WL12 sensor, Industrial object sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor
- Sensing range: 0 m to 1.3 m (standard), up to 2 m without reflector
- Light source: Visible red LED, 640 nm wavelength
- Adjustment: Potentiometer, 5 turns
- Switching mode: Light/dark switching
- Output type: PNP digital output, complementary function
- Max output current: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Protection class: III
- Housing material: Metal with plastic PMMA front screen
- Connection: Male M12, 4-pin connector
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40°C to +60°C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 2 meters without reflector
- Polarisation filter for improved detection
- Visible red LED light source with 640 nm wavelength
- Potentiometer adjustment with 5 turns
- Focused optics for detecting small objects
- High switching frequency of 1,500 Hz
- IP66, IP67, and IP69K rated for harsh environments
- Operating temperature range from -40°C to +60°C
- Metal housing with plastic PMMA front screen
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Small object detection in manufacturing lines
- Safety and control systems requiring precise sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP69K rated housing minimizes environmental impact by extending product life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK WL12-3P2451 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
