Photoelectric Retro-Reflective Sensor | 7m Sensing Range | PNP Digital Output | IP66/IP67/IP69K Rated | by SICK
The Photoelectric Retro-Reflective Sensor WL12-3P2431T01 is designed for industrial automation, featuring a sensing range of up to 7 meters without a reflector and a fast response time of ≤ 330 µs. With its durable Teflon-coated metal housing and IP66/IP67/IP69K ratings, this sensor is perfect for hygienic applications and robust environments, ensuring reliable object detection and safety in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with autocollimation optics
- Sensing range: 0 m to 7 m without reflector, 0 m to 5 m typical
- Light source: Visible red LED, wavelength 640 nm
- Light spot size: Ø 70 mm at 3 m distance
- Adjustment: Potentiometer with 5 turns
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Output type: PNP digital output, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Protection class: III
- Housing material: Metal zinc diecast with PTFE coating
- Connection: Male M12, 4-pin connector
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40°C to +60°C
- Storage temperature: -40°C to +75°C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 7 meters without reflector
- Polarisation filter for improved detection reliability
- Visible red LED light source with 640 nm wavelength
- Teflon coated metal zinc diecast housing for durability and hygienic applications
- IP66, IP67, and IP69K rated for protection against dust and water
- Operating temperature range from -40°C to +60°C
- Light/dark switching mode with PNP digital output
- Fast response time of ≤ 330 µs and switching frequency up to 1,500 Hz
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure correct sensor alignment and electrical connection according to safety standards.
Applications
- Industrial automation for object detection
- Hygienic and washdown zones requiring robust sensors
- Safety and presence detection in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- Energy-efficient LED light source minimizes power consumption
- High ingress protection extends product lifespan in harsh environments
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK WL12-3P2431T01 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and hygienic zone applications.
