Photoelectric Retro-Reflective Sensor | Dual Lens System | IP66/IP67/IP69K Rated | 0.15m to 10m Range | by SICK
The Photoelectric Retro-Reflective Sensor is designed for industrial automation, featuring a dual lens system for precise object detection. With a sensing range of 0.15 m to 10 m and an IP66/IP67/IP69K enclosure rating, it ensures reliable performance in harsh environments. Ideal for safety and monitoring in manufacturing processes, this sensor operates efficiently within -30 °C to +60 °C, making it perfect for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.15 m to 8 m (max 10 m)
- Focus angle: Approx. 2.2°
- Light source: Visible red LED, wavelength 640 nm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP, complementary
- Switching mode: Light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 2.5 ms
- Switching frequency: 200 Hz
- Connection type: Male connector M12, 4-pin
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -30 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Weight: 120 g
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light LED with wavelength of 640 nm
- Sensing range from 0.15 m to 8 m, max 10 m
- Rectangular housing design with IP66, IP67, and IP69K enclosure rating
- Single teach-in button for easy adjustment
- High switching frequency of 200 Hz and response time ≤ 2.5 ms
- Complementary PNP output with light/dark switching mode
- Polarisation filter and special device features included
- Operating temperature range from -30 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper setup and compliance with electrical standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable housing materials extend product lifespan, reducing waste
- High reliability minimizes downtime and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WL11-2P2432P07 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
