Photoelectric Retro-Reflective Sensor | Dual Lens System | IP67 & IP69K Rated | 0.03m to 6.5m Sensing Range | by SICK
The Photoelectric Retro-Reflective Sensor HL18-L5B3AA features a dual lens system for precise object detection, with a sensing range of 0.03m to 6.5m. Designed for industrial automation, this sensor operates efficiently with a high switching frequency of 1,000 Hz and a response time of ≤ 0.5 ms. Its robust IP67 and IP69K rated enclosure ensures durability in harsh environments, making it ideal for safety monitoring and material handling applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.03 m to 6.5 m
- Light source: PinPoint LED, wavelength 631 nm
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with male micro connector, 4-pin, 150 mm
- Housing material: Plastic VISTAL®, optics material: Plastic PMMA
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Storage temperature: -40 °C to +75 °C
- Protection class: II
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Hybrid housing design with M18 thread diameter
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- MOSFET switching output with light switching mode
- IP67 and IP69K rated enclosure for robust protection
- Wide ambient operating temperature range from -40 °C to +70 °C
- Polarizing filter included to reduce interference
- Cable with male micro connector, 4-pin, 150 mm length
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection according to industrial safety standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤ 10 mA current draw
- Durable IP67/IP69K housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HL18-L5B3AA Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
