Photoelectric Retro-Reflective Sensor HL18T-M1G3AB | Dual Lens System | IP67 & IP69K Rated | by SICK
The Photoelectric Retro-Reflective Sensor HL18T-M1G3AB features a dual lens system and a sensing range of 0.1 m to 3 m, making it ideal for industrial automation and object detection. With a robust IP67 and IP69K rating, this sensor is built to perform in harsh environments, ensuring reliable detection of transparent objects. Its low power consumption and high switching frequency of 1,000 Hz enhance efficiency in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective with dual lens system
- Sensing range: 0.1 m to 3 m
- Light source: PinPoint LED, visible red light, 631 nm wavelength
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, dark switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable open end, 2 m, PVC
- Protection class: II
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Weight: 18 g
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Visible red light PinPoint LED with 631 nm wavelength
- Sensing range from 0.1 m to 3 m
- MOSFET switching output with dark switching mode
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing with IP67 and IP69K protection
- Polarizing filter included for reliable detection
- Wide operating temperature range from -40 °C to +70 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor equipment to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Use in harsh environments requiring IP67/IP69K protection
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with ≤ 10 mA current draw
- Durable housing reduces waste through extended product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HL18T-M1G3AB Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
