Photoelectric Retro-Reflective Sensor WL34-V540 | Dual Lens System | IP67 Rated | by SICK
The WL34-V540 Photoelectric Retro-Reflective Sensor is designed for industrial automation, featuring a dual lens system for precise object detection up to 15 meters. With a visible red LED light source and selectable switching modes, it ensures reliable performance in various applications, including safety monitoring and material handling. Its robust IP67 housing guarantees durability in challenging environments, making it an ideal choice for professionals seeking efficiency and reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Retro-Reflective Sensor WL34-V540 | Dual Lens System | IP67 Rated | by SICK
Brand: SICK
SKU: 1019248
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK WL34 sensor, Industrial photo sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.03 m to 15 m (max 22 m)
- Light source: Visible red LED, wavelength 660 nm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 50 mA
- Switching output: NPN, PNP selectable
- Switching mode: Light switching, Dark switching selectable
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1,000 Hz
- Time functions: Adjustable off delay and switch-on delay (0.5 s to 10 s)
- Connection type: Plug, M12, 5-pin
- Circuit protection: Types A, C, D
- Protection class: II
- Enclosure rating: IP67
- Ambient operating temperature: –40 °C to +60 °C
- Housing material: Plastic, ABS
- Weight: 140 g
- Polarisation filter included
- Dimensions (H x L x W): 92mm x 70mm x 27mm
- Weight: 0.14 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light LED with wavelength of 660 nm
- Adjustable potentiometer for sensitivity and delay time
- Selectable switching modes: light switching and dark switching
- NPN and PNP switching outputs with up to 100 mA output current
- High switching frequency of 1,000 Hz and fast response time ≤ 500 µs
- Time functions include adjustable off delay and switch-on delay
- Robust plastic ABS housing with IP67 enclosure rating
- Wide ambient operating temperature range from –40 °C to +60 °C
- Polarisation filter included for improved detection reliability
- Plug connection type: M12, 5-pin
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and conveyor systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP67 housing extends product life and reduces waste
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WL34-V540 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
