Photoelectric Retro-Reflective Sensor RAY10-AB5EBL | Dual Lens System | IP67 Rated | by SICK
The Photoelectric Retro-Reflective Sensor RAY10-AB5EBL features a dual lens system for precise object detection, with a minimum object size of 5 mm and a sensing range of up to 1.5 meters. Ideal for industrial automation, this sensor operates efficiently in harsh environments, thanks to its robust IP67-rated housing and wide temperature range from -40°C to +60°C. Perfect for detecting various object types, it ensures reliable performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Minimum object size: 5 mm
- Detection height: 25 mm
- Sensing range max.: 0 to 1.5 m
- Light source: PinPoint LED, wavelength 635 nm
- Adjustment: Potentiometer
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: Push-pull PNP/NPN
- Switching mode: Light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Connection type: Cable with male M8, 4-pin connector, 1 m length
- Cable material: PVC, diameter 3.6 mm
- Protection class: III
- Housing material: Plastic ABS
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -40°C to +60°C
- Storage temperature: -40°C to +70°C
- Dimensions (H x L x W): 36mm x 38mm x 22mm
- Weight: 0.13 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Minimum object size detection of 5 mm
- Sensing range up to 1.5 meters
- Visible red light with PinPoint LED light source
- Potentiometer adjustment for sensitivity
- Light/dark switching mode with push-pull PNP/NPN output
- High switching frequency of 1000 Hz and response time ≤ 0.5 ms
- Robust plastic ABS housing with IP67 enclosure rating
- Wide ambient operating temperature range from -40°C to +60°C
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Detecting transparent, perforated, uneven, shiny, and flat objects
- Position-independent detection within light array
- Use in harsh environments with IP67 protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable design reduces waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK RAY10-AB5EBL Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
