Photoelectric Retro-Reflective Sensor WL9G-3F2232 | IP66/IP67/IP69K | 5m Sensing Range | by SICK
The Photoelectric Retro-Reflective Sensor WL9G-3F2232 is designed for industrial automation, featuring a robust IP66/IP67/IP69K rating and a sensing range of up to 5 meters. With its visible red light and single teach-in button, it effectively detects transparent objects, making it ideal for manufacturing environments. Built to operate in harsh conditions, this sensor ensures reliability and efficiency in your applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP complementary
- Switching mode: Light/dark switching
- Output current max: ≤ 100 mA
- Response time: < 0.5 ms
- Switching frequency: 1000 Hz
- Connection type: Male connector M8, 4-pin
- Circuit protection: Types A, B, C
- Protection class: III
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Light spot size at 1.5 m: Ø 45 mm
- Sensing range max: 5 m
- Sensing range typical: 3 m
- Dimensions (H x L x W): 50mm x 24mm x 12mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Visible red light with PinPoint LED at 650 nm wavelength
- Single teach-in button for easy adjustment
- AutoAdapt feature for optimized sensing
- Detects transparent objects effectively
- High protection rating: IP66, IP67, IP69K
- Operating temperature range from -40°C to +60°C
- Polarizing filter included to reduce false triggers
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Use in harsh environments requiring IP66/IP67/IP69K protection
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Energy-efficient operation with low current consumption (20 mA)
- Durable housing materials extend product life reducing waste
- High reliability reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK WL9G-3F2232 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and transparent object detection applications.
