Photoelectric Retro-Reflective Sensor WL9-3N1102P08 | IP66, IP67, IP69K | 650 nm PinPoint LED | by SICK
The Photoelectric Retro-Reflective Sensor WL9-3N1102P08 is designed for precise object detection in industrial automation. With a small light spot size of Ø 3 mm and a wide operating temperature range from –40 °C to +60 °C, it ensures reliable performance in various environments. Ideal for manufacturing process control and material handling, this sensor features a high protection rating and easy installation with a single teach-in button.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: NPN, complementary
- Switching mode: Light/dark switching
- Maximum output current: ≤ 100 mA
- Response time: < 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: 4-wire cable, 2 m length, PVC material
- Circuit protection: Types A, B, C
- Protection class: III
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: –40 °C to +60 °C
- Storage temperature: –40 °C to +75 °C
- Light spot size: Ø 3 mm at 35 mm distance
- Sensing range max: 0 mm to 290 mm
- Sensing range typical: 0 mm to 125 mm
- Dimensions (H x L x W): 50mm x 23.6mm x 12.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with visible red light
- PinPoint LED light source with 650 nm wavelength
- Small light spot size of Ø 3 mm at 35 mm distance
- Single teach-in button for easy adjustment
- Front screen printing for a small light spot
- High protection rating: IP66, IP67, IP69K
- Wide ambient operating temperature range from –40 °C to +60 °C
- Polarizing filter included
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for detecting small objects
- Manufacturing process control
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable housing materials extend product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK WL9-3N1102P08 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
