Photoelectric Retro-Reflective Sensor WL34-R230 | IP67 Rated | 0.03m to 22m Sensing Range | Fast Response Time | by SICK
The Photoelectric Retro-Reflective Sensor WL34-R230 is designed for industrial automation, featuring a sensing range from 0.03m to 22m and a fast response time of ≤ 10 ms. With an IP67 rated enclosure, it ensures reliable performance in harsh environments, making it ideal for safety and control systems in manufacturing and material handling applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Optical sensor, Industrial photo sensor
Technical Specifications
- Supply voltage: 20 V AC/DC to 250 V AC/DC
- Power consumption: < 2 VA
- Switching output: Relay, electrically isolated
- Switching current: 4 A @ 250 V AC, 4 A @ 24 V DC
- Response time: ≤ 10 ms
- Switching frequency: 10 Hz
- Light source: LED, visible red light at 660 nm
- Light spot size at 15 m: Ø 250 mm
- Protection class: II
- Enclosure rating: IP67
- Ambient operating temperature: -40 °C to +60 °C
- Housing material: Plastic, ABS
- Connection type: Terminal connection with M16 gland
- Usage category: AC-15, DC-13 according to EN 60947-1
- Dimensions (H x L x W): 92mm x 70mm x 27mm
- Weight: 0.14 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Sensing range from 0.03 m up to 22 m
- Visible red LED light source with 660 nm wavelength
- Relay output with change-over contacts
- Selectable light/dark switching mode
- IP67 rated enclosure for dust and water protection
- Wide operating temperature range from -40 °C to +60 °C
- Terminal connection with M16 gland
- Plastic ABS housing with rectangular light emission design
- Fast response time of ≤ 10 ms and switching frequency of 10 Hz
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper sensor operation.
Applications
- Industrial automation for object detection
- Safety and control systems in manufacturing
- Material handling and packaging lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption of less than 2 VA reduces energy usage
- Durable IP67 housing extends product life and reduces waste
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK WL34-R230 Photoelectric Retro-Reflective Sensor is available now for immediate purchase. Ideal for industrial automation and safety control applications.
