Photoelectric Retro-Reflective Sensor RAY10-HK3GBL | IP67 Rated | 1.5m Sensing Range | PNP Output | by SICK
The RAY10-HK3GBL Photoelectric Retro-Reflective Sensor is designed for precise object detection in industrial automation. With a sensing range of up to 1.5 meters and a high switching frequency of 1000 Hz, it effectively detects various object types, including transparent and shiny surfaces. Its durable IP67 rated enclosure ensures reliable performance in challenging environments, making it ideal for a wide range of applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Connection: Cable with M8 male connector, 4-pin, 2 m
- Housing material: Plastic ABS
- Optics material: Plastic PMMA
- Protection class: III
- Enclosure rating: IP67
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +70 °C
- Light source: PinPoint LED, 635 nm wavelength
- Light spot size at 1 m: 37 mm x 12 mm
- Dimensions (H x L x W): 36mm x 38mm x 22mm
- Weight: 0.13 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Minimum object size detection of 5 mm
- Sensing range up to 1.5 m
- Visible red light with PinPoint LED at 635 nm wavelength
- Potentiometer adjustment
- Light/dark switching mode with PNP output
- High switching frequency of 1000 Hz
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40 °C to +60 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with electrical standards.
Applications
- Industrial automation for object detection
- Detecting transparent, perforated, uneven, shiny, and flat objects
- Position-independent detection within light array
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP67 housing minimizes environmental impact by extending product life
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK RAY10-HK3GBL Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
