Photoelectric Retro-Reflective Sensor | IP67 & IP69K Rated | 0.03m to 6.5m Sensing Range | by SICK
The Photoelectric Retro-Reflective Sensor HL18-M1G3AH is designed for industrial automation, featuring a sensing range from 0.03m to 6.5m and a high switching frequency of 1,000 Hz. With an IP67 and IP69K rated enclosure, it ensures robust protection in harsh environments, making it ideal for safety monitoring and object detection in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable open end, 2 m, plastic PVC, conductor cross section 0.2 mm²
- Protection class: II
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Storage temperature: -40 °C to +75 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Hybrid housing design with M18 thread diameter
- Dark switching MOSFET output with up to 100 mA output current
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- IP67 and IP69K rated enclosure for robust protection
- Operating temperature range from -40 °C to +70 °C
- Includes fastening nut M18, plastic, black, flat
- Polarizing filter included to reduce interference
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper mounting and electrical connection according to safety standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and conveyor systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤ 10 mA current draw
- Durable IP67/IP69K rated housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HL18-M1G3AH Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
