Photoelectric Retro-Reflective Sensor | M18 Threaded Housing | IP67 Rated | 4.2m Sensing Range | by SICK
The Photoelectric Retro-Reflective Sensor is designed for industrial automation, featuring a robust M18 threaded housing and an impressive sensing range of up to 4.2 meters. With a fast response time of ≤ 500 µs and an IP67 rating for dust and water protection, this sensor is perfect for manufacturing process control and safety monitoring in production lines. Its dual lens system and visible red LED light source ensure reliable object detection in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 15 mA
- Switching output: PNP, dark switching
- Output current max: 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1,000 kHz
- Connection type: Terminal connection Wago 733-103, 3-pin, 2 m cable
- Cable material: Plastic, PVC
- Conductor cross section: 0.13 mm²
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Operating temperature: -40 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Thread diameter: M18
- Light spot size at 1000 mm: Ø 125 mm
- Wave length: 625 nm
- Dimensions (H x L x W): 34.8mm x 21.9mm x 13.6mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red LED light source with 625 nm wavelength
- Sensing range up to 4.2 meters, max 5 meters
- Hybrid housing design with transparent color
- M18 threaded housing for head/side mounting
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -40°C to +55°C
- PNP switching output with dark switching mode
- Fast response time ≤ 500 µs and switching frequency up to 1,000 kHz
- Terminal connection Wago 733-103, 3-pin, 2 m cable with PVC insulation
- Polarisation filter included for enhanced detection reliability
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67 housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK ZLD18-BFZCG8P32 Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control applications.
